Test bench
How to set up your own mini lab
By Bulan Sarkar, founder of ElectronicsInfoline (since 2000) · About a 10-minute read
A home electronics lab fits on one desk. What makes it work is a few instruments you trust and the habit of powering new circuits gently. This page sets out the desk, the order to buy things in, and the numbers behind each choice.
The instrument figures come from the data sheets of two common bench tools, a RIGOL DP711 linear supply and a Fluke 17B+ multimeter. The soldering temperatures come from Kester's alloy chart and wire data sheet. Any supply or meter of the same class works the same way; read your own data sheet for its numbers.
To set up a small electronics lab at home, start with a desk at least 600 mm deep, a multimeter, a temperature-controlled soldering iron, a breadboard and a resistor kit. Add a bench power supply with a current limit next, then an oscilloscope. Keep the instruments on a shelf over the back of the desk so the front 400 mm stays free for the work.
Then power every new board from the bench supply with the current limit set a few times above what it should draw: at 100 mA and 5 V, a fault can take at most 0.5 W, against 25 W with the limit wide open.
A mini lab, worked
- Most power into a board at a 100 mA limit
- 0.5 W
- Supply display error at 25 mA
- ±20 mA
- Same reading on a meter in series
- ±0.41 mA
- Lead-free tip, low end
- 371 °C (700 °F)
What a mini lab needs
Every bench does four jobs: it powers a circuit, measures it, joins parts together and stores the parts. A lab built for microcontroller boards, sensors, small amplifiers and battery projects works at bench voltages, a few volts to a few tens of volts, which is what everything below assumes. Mains repair needs more than this page covers (see the questions at the end).
If you are starting from nothing, the repair and test bench path walks through the lessons in order, and where to buy components in India covers the shops and markets.
The desk and where things go
Check the desk depth first. A linear bench supply is deep because its transformer and heatsink sit behind the front panel: the DP711 is 332 mm deep and weighs 6.9 kg (RIGOL). Stand it on a 600 mm desk and only 268 mm is left in front of it, less than an A4 sheet is long. Add a scope beside it and there is no room to work.
A simple shelf riser, a plank on two end supports about 250 mm high, gives the instruments their own level and puts the displays near eye height. The supply is 202 mm tall, so that clearance also lets you slide things under the shelf. Keep the iron on the side of your writing hand, the parts on the other, and the lamp over the shelf so it lights the mat without glare off the screens. A silicone or anti-static mat protects the desk from the iron and gives small parts something to sit on.
What to buy, in order
Buy things in the order you will need them. The first group lets you build and check simple circuits from a USB supply. The second makes new boards safe to power and lets you see signals. The third is for when a project asks for it.
The oscilloscope has its own page: five oscilloscopes for a home lab works out bandwidth, sample rate and probes for the signals a hobby bench sees. For the multimeter, a 4000-count meter with a 40 mA range is plenty to start with; the next two sections show why that range matters.
The bench supply: set the current limit first
A bench supply holds its output at the voltage you set (constant voltage, CV) until the load tries to draw more than the current limit. Then it holds the current at the limit instead and lets the voltage fall (constant current, CC). The DP711 runs from 0 to 30 V and 0 to 5 A, and its protection can be set anywhere from 10 mA to 5.5 A (RIGOL).
That limit is what protects a new board. Whatever goes wrong on it (a solder bridge, a chip in backwards, a reversed capacitor), the supply cannot deliver more than the set voltage times the limit. Our example is a 5 V microcontroller board that should draw about 25 mA.
A limit is not exact. The DP711 sets current to within ±(0.2 % + 10 mA) (RIGOL), so a 100 mA setting trips somewhere between 89.8 mA and 110.2 mA. That is why the limit sits about four times above the expected current rather than just over it. Cheaper supplies are less precise again, so leave more room.
Our take: a supply with a real current limit is the second thing to buy, after the meter. A phone charger or a USB port has no limit you can set, so a fault on a new board draws whatever the charger can supply.
Measuring a board's current
The supply's display shows the current, so it is tempting to read it there. For a small board that number means little. The DP711's readback is accurate to ±(0.2 % + 20 mA) and its standard display steps in 10 mA (RIGOL). At 25 mA that is ±20.1 mA: the true current could be anywhere from about 5 mA to 45 mA.
A multimeter in series does far better. On the Fluke 17B+'s 40 mA range the accuracy is ±(1.5 % + 3 counts) with 0.01 mA resolution (Fluke), which at 25 mA is ±0.41 mA, about 50 times tighter.
Two cautions. Move the red lead back to the volts socket as soon as you finish: a meter left on a current range is a short circuit across whatever you probe next. And a meter on a current range drops a little voltage across its shunt, so the board sees slightly less than the supply shows; read the voltage across the board itself, as in figure 4.
First power-up, step by step
With the limit and the meter in place, bringing up a new board is a short routine. Work down the chart; any "yes" on the left means switch off and look before going on.
The resistance check is done with the power off: a reading of a few ohms from the 5 V rail to ground usually means a solder bridge or a part in backwards. Some boards read low for a moment while their capacitors charge from the meter, so watch for the number to climb. Once the board passes, raise the limit to whatever its full load needs, such as a motor or a radio transmitting.
Soldering station and temperatures
Get an iron with a temperature setting. Solder melts at a fixed point, but the tip has to be well above it to push heat into a pad and a lead quickly. Kester lists Sn63Pb37 as melting at 183 °C (361 °F) and SAC305 (tin, 3 % silver, 0.5 % copper, the common lead-free wire) over 217–220 °C (423–428 °F) (Kester). Its wire data sheet puts the iron tip at 315–371 °C (600–700 °F) for leaded wire and 371–427 °C (700–800 °F) for lead-free (Kester). Irons sold in the US often show °F, so set the dial from the figure in brackets.
Lead-free work needs about 56 °C more at the tip, so an iron that only just copes with leaded wire will struggle with lead-free. And hotter is not better. Start at the bottom of the range and go up only if a joint takes more than two or three seconds to flow. Kester also says to heat the pad and the lead first and feed the wire to the joint, not to the tip (Kester). The soldering basics lesson shows what a good joint looks like. Put a small fan at the side of the mat so the flux smoke drifts away from your face.
Parts drawers
Resistors come in standard series. In the E12 series each decade has twelve values (Vishay), spaced so that each is roughly 20 % above the last. That spacing means any value you want is close to one you have: the widest gap is 12 to 15, a step of 25 %, so nothing is more than about 11.8 % from an E12 value.
A starter kit from 10 Ω to 1 MΩ covers five decades: 60 values plus 1 MΩ itself, 61 in all. With 10 of each that is 610 resistors, which fits a small drawer cabinet if you give each decade a row. Label the drawers with the value in figures, which is quicker to read than a colour code. For capacitors, the E6 series (10, 15, 22, 33, 47, 68) in ceramic from 10 pF to 100 nF and electrolytic from 1 µF up covers most hobby circuits. If a value is missing, two resistors in series or parallel can get closer; the resistor combination finder works that out.
The mains side: one strip, counted
All the instruments plug into the mains, so count what they draw before sharing one strip. The DP711's maximum input is 400 VA (RIGOL), far more than its 150 W output: a linear supply loses much of the difference as heat. The other figures below are our example ratings; use the ones printed on your own gear.
At 2.7 A the whole bench is under half of what a 6 A strip is rated for (1,380 VA at 230 V). On 120 V mains the same bench draws 5.2 A, and a common 15 A strip carries 1,800 VA, so the bench uses about 34 % of it. The numbers change if you add a heat gun or a space heater on the same strip, so check the strip's printed rating and the socket it plugs into. Use one strip with a switch you can reach, so the whole bench goes off with one press at the end of the day, and keep the iron's cable away from the other leads. Leave any new socket or wiring to a licensed electrician, and follow the local code: the NEC in the US, BS 7671 in the UK, IS 732 in India.
Tips and checks
- Set the supply's voltage and limit with the output off, then switch the output on. Turning the knob with a board connected can overshoot.
- Check your meter on a known voltage when you get it, such as a fresh 1.5 V cell, and write the reading on a label inside the lid.
- Keep a short set of leads (crocodile clips, banana to clip) for the supply. Long thin leads drop voltage at high current and pick up noise.
- Wipe the iron tip on brass wool and tin it before you put it in the holder. A tip left dry at 371 °C oxidises fast.
- Write the expected current on the schematic before the first power-up, so you have a number to compare against.
- Keep a notebook on the bench: board, date, limit set, current measured. The next time a board misbehaves, you can compare it with the last good reading.
Questions people ask
What equipment do I need for a home electronics lab?
To start: a multimeter, a temperature-controlled soldering iron, a breadboard with jumpers, an E12 resistor kit and cutters. Next: a bench supply with a current limit and an oscilloscope. A function generator and a logic analyser can wait until a project needs them.
How much space does a home lab need?
A desk about 1200 × 600 mm is enough if the instruments sit on a shelf over the back. A linear bench supply is about 332 mm deep, so on the desk itself it leaves only 268 mm to work in.
What temperature should my soldering iron be?
Kester puts the tip at 315–371 °C (600–700 °F) for leaded Sn63Pb37 wire and 371–427 °C (700–800 °F) for lead-free wire. Start at the low end and raise it only if joints are slow to flow.
Do I need a bench power supply, or is a USB charger enough?
A USB charger runs a finished 5 V board. A new or repaired board should go on a bench supply with the current limit set low, so a fault gets 0.5 W instead of whatever the charger can give.
Can I repair mains appliances on this bench?
Not as set up here. Mains work needs an isolation transformer, a meter and probes rated for it (see the CAT ratings lesson), and the habit of proving a circuit dead before touching it. Keep this bench for battery and low-voltage work.
